Diaphragm dry pump TV-D120H
TV series adopts imported diaphragm and valve parts, durable, oil-free, ultra-quiet, low power consumption, and overload protection, is a cost-effective dry vacuum pump. TV series vacuum pumps are mainly used in automation equipment, vacuum packaging equipment, LED equipment, LCD touch equipment, engraving machine equipment, electronic semiconductors, printing machinery equipment and other fields.
Classification:
Small dry vacuum pump
Key words:
Small dry vacuum pump
Contact Us
- Product features and uses
- Product parameters and graphs
-
| Features
1, self-lubricating, oil-free, maintenance-free
2, ultra-quiet, noise around 50 decibels, extremely low vibration,
3, low power consumption, overload protector, no burn
4 due to overload, vacuum as high as-98kPa to 100kPa
5, diaphragm, valve plate, etc. all adopt imported accessories, durable| UsesProducts are widely used in:
, automatic equipment vacuum fixing and handling
2, vacuum packaging equipment
3, LED equipment
4, liquid crystal touch equipment
5, woodworking machinery equipment
6, engraving machine equipment
7, vacuum defoaming machine
8, printer
9, manipulator
10, laboratory
11, mounter
12, binding machine
13, electronic semiconductor
14, printing equipment
15, medical beauty equipment
-
| Specification Parameter.75 0.45 0.75 0.75 210 motor voltage single phase/50Hz V single phase 220V thermal protection function - YES#
Type TV-60V TV-60H TV-100V TV-100H TV-130V TV-130H TV-200V TV-200H TV-260V TV-260H TV-D120H Flow L/min 60 40 100 70 130 100 200 180 260 220 120 vacuum degree Pa ≦ 6 × 10 3 ≦ 1 × 10 3 ≦ 6 × 10 3 ≦ 1 × 10 3 ≦ 6 × 10 3 ≦ 1 × 10 3 ≦ 6 × 10 3 ≦ 1 × 10 3 ≦ 6 × 10 3 ≦ 1 × 10 3 ≦ 1 × 10 3 Noise dB(A) 48 48 52 52 53 53 55 55 55 55 55 Motor Power kW 0.1 0.1 0.23 0.23 0.35 0.35 0.45 YES YES YES YES YES YES YES YES YES YES Ambient Temperature C - 5~40 Weight kg 3.5 3.5 6.5 6.5 0.9 0.9 10.5 10.5 17 17 11 Remarks Optional silencer, shock absorber | curve
